UN38.3 MSDS Lithium Electric Bike Battery 36V 10-40AH 800 Cycle Times

UN38.3 MSDS Lithium Electric Bike Battery 36V 10-40AH 800 Cycle Times

Product Details:

Place of Origin: China
Certification: ISO 9001,UL,CE,MSDS,etc

Payment & Shipping Terms:

Minimum Order Quantity: 100PCS
Price: Negotiable
Packaging Details: Standard Export Carton,Wooden Case ,Pallet etc.
Delivery Time: 7~30 days
Payment Terms: T/T
Supply Ability: 3500 Per Months
Get Best Price Contact Now

Detail Information

Cell Brand: CATL/BYD/Domestic/EVE/SANYO/Samsung/Panasonic,etc. Cell Material: Lithium Iron Phosphate Battery/Ternary/NIMH/NCM,etc
Capacity: 30AH/Customized(8AH,20AH,40AH) Voltage: 36V/Customized(48V/52V)
Cycle Life: More Than 800 Cycle Times Discharging Temperature: -20℃~60℃
Connection Method: 10S8P/Customized LED Indicator: Yes
High Light:

MSDS Lithium Electric Bike Battery

,

Lithium Electric Bike Battery 36V

Product Description

Top Tube Type UN38.3/MSDS Approved High Safety 36V 10AH~40AH Redar Electric Bicycle Pack For Electric Folding Bike



Quick Details:

  • Built-in battery indicator light, check the power consumption anytime, anywhere

  • the battery cell passed the MSDS/CE/UN38.3 there is not any pollution at all.

  • Strong metal shell, waterproof and anti-corrosion, strong and durable

  • High Energy Density ,Each Battery Can be Fully Charging And Discharging

  • Perfect Match With Original Product

  • Flexible packaging, laminated type, lean liquid, good safety

  • Great Factory Price with Best Quality and After-Selling Service



​Application:Electric  Bike/Electric Scooter/Electric Two Wheels Vehicles/Electric Three Wheels Vehicles/E-Bike/E-Scooter/Electric Motorcycle

Electric Folding Bike/Golf Cars/Electric Wheeled Chairs



How to buy the right electric vehicle battery:

1.Please confirm the voltage and capacity of the electrified equipment
2.Please confirm the motor power value
3.Battery size, optional factory fixed size or customized size





Specification
Nominal Capaity 30AH
Nominal Voltage 36V
Connection Method 10S8P
SOC Display Yes
Charge Voltage 42.0 V
Discharge Cut-Off Voltage 25.0 V
Standard Charge Charge the battery at constant current of 0.2C to reach 42.0V.
Then charge the battery at constant 42.0V voltage until the charging current decreasing to 0.02C.
Standard Discharge After the standard charging, rest for 1 hour then discharge to 25.0V@0.2C.
Maximum Continuous Discharge Current 15A
Pulse Maximum Discharge Current 40 A
Rated Capacity Typical capacity: 8.7Ah
Minimum capacity: 8.25Ah -5%
Operation Charging: 10~45°C
Temperature Range Discharging: -20~60°C
Storage ≤1 month: - 20~45*C
Temperature ≤3 months: -10 ~ 25C
  ≤1year: 0 ~ 30°C
Impedance ≤160mΩ
Size Of Battery Pack ≈365*105*92mm
Items Test Conditions
Capacity Retention Fully charging, store them at (20 ± 5)℃ for
28 days, then discharge to 30.0V @0.2C.
Cycle Life @251 Discharge to 30.0V @0.2C, then Charge the battery @0.2C to reach 42.0V. Then charge the battery at constant 42.0V voltage until the charging current decreasing to 0.02C. Rest for 10 min. discharge to 30.0V@ 0.2C and rest for 10 min. Continue the charge/discharge cydes until discharge capacity lower than 80% of rated capacity.
Storage Charge the battery to 40%~65% of its rated capacity using standard charging mode, then keep it in an 20t ± 5*C, humidity 45% ~ 85% room for 12 months, fully charge and discharge it @0.2C until voltage down to 30.0V.
(The testing sample should be within 3 months dated from production date)
Vibration Test After standard charging, put battery on the vibration table. 30 min experiment from X, Y, Z axis. Scan rate: 1oct/min; Frequency 10-30Hz, Swing 0.38mm; Frequency 30-55Hz, Swing 0.19mm.
Drop Test Random drop the battery from 1.0m height onto wood board 2 times.







UN38.3 MSDS Lithium Electric Bike Battery 36V 10-40AH 800 Cycle Times 0







UN38.3 MSDS Lithium Electric Bike Battery 36V 10-40AH 800 Cycle Times 1



UN38.3 MSDS Lithium Electric Bike Battery 36V 10-40AH 800 Cycle Times 2





UN38.3 MSDS Lithium Electric Bike Battery 36V 10-40AH 800 Cycle Times 3







UN38.3 MSDS Lithium Electric Bike Battery 36V 10-40AH 800 Cycle Times 4





UN38.3 MSDS Lithium Electric Bike Battery 36V 10-40AH 800 Cycle Times 5





What can we offer?

1.Competitive price: factory price, we can give you more discount if order quantity is good.

2. Technical support : we have 20 person R&D team, can help you solve any technical problems and provide customized battery solutions according to your needs.

3. Quality Assurance:we have our own testing lab, all the batteries have 100% QC inspection before delivery, and we can provide testing reports for you.

4. After-sale service: we have excellent after-sale service team, if you have any question about this product,plus feel free to contact us, we'll reply you within 12 hours.

5. Customized battery solutions based on customer's needs, accept OEM/ODM orders.





Packing Details:

Strong and protective package way will protect each battery well.

Base on different transportation way, the battery package will be customized.

Different transportation way will be selected according to customers' requirements.





Logistic Time:



- Material Preparation Time: 7-15 days (or inventory)



- Production & Assembly Time 3-10 days



- Testing & Packaging Time: 2-10 days



- Total Delivery Time: 30-45days



- The faster delivery could be negotiable.





FAQ:

Q1. Can I have a sample order?

A. Yes, we welcome sample order to test and check quality.



Q2. Do you have any MOQ limit?

A.Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ, 1pc for sample checking is available.



Q3. How to proceed with an order?

A. Firstly let us konw your requirements or application. Secondly, we quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places a deposit for formal order. Fourthly we arrange the production.



Q4. Is it OK print my logo on the product?

A. Yes. Please inform us formally before our production and confirm the design firstly based on our sample.



Q5. Which certificates do you have?

A. We have CE/FCC/ROHS/UN38.3/MSDS ... etc.



Q6. How about warranty?

A. 1 years warranty. Enable to prolong.







Welocme to inquiry ,Thank you !!
